Waida Manufacturing Co. Ltd.
Optical & Digital Profile Grinders
WAIDA Optical & Digital Profile Grinding Machines:
Waida optical profile grinders are a standard in the industry and needs no introduction.
SPG-XV
Next generation profile grinding machine equipped with a digital projector.
It inherits the advantages of conventional projectors and creates value.
Equipped with a high-precision digital projector, direct import of CAD data, no need for drawing with a chart plotter
Eliminates visual errors caused by operators and achieves precise measurement
Abundant software to support the operator can shorten the total processing time.
Equipped with a height-adjustable monitor and pendant
The stroke unit can be selected from a linear motor type with high operability or a conventional reciprocating link type.
Up/down stroke is
Linear motor type: 160mm
Reciprocating link type: 110mm
fully-covered design support for safety and ease of use (option)
SPG-X
Standard Optical Profile Grinder with improved operability and visibility.
Equipped with LED transmitted illumination replacing conventional halogen illumination.
The projector is made in-house. Provides visibility under strict quality control. Reliable support due to in-house production.
Equipped with a new type of LED transillumination as standard to provide a clear projection image.
Abundant options (vertical indexing device, cylindrical device, etc.) are available to meet various processing needs.
WAIDA's original software "SPG Lab" (option) is adopted.
Supports an operator-friendly work environment both on and off the machine.
The stroke unit can be selected from a highly operable linear motor type or a conventional reciprocating link type.
Up/down stroke is
Linear motor type: 160mm
Reciprocating link type: 110mm
fully-covered design support for safety and ease of use (option)
Components Processed on Waida Optical Profile Grinders:
*Hover the mouse on proudct images to view details*.
SPG-XV
SPG-X
Components Processed on Waida Optical Profile Grinders
